The whole corpus, rendered live

All 21 governing-corpus images side by side: the original, the scripted pixel runtime evaluating the splat formula in your browser, the scriptless CSS build as real DOM composited from a stylesheet, and the corrected-exporter SVG as a true vector — every one of them the deployed artifact itself, drawn live by your browser, because GitHub Pages applies no sanitizer. PowerPoint is the one target that cannot render live: its column is a real Microsoft PowerPoint slideshow capture, with the editable deck one click away.

Rows are ordered best-to-worst by deployed SVG LPIPS. Every score is a seed-0 measurement of these exact artifact families against the source in the governing renderer — Chromium for the browser targets, real PowerPoint for the decks — quoted from the versioned ledgers. The page is generated by tools/build_corpus_gallery.py; SVGs use the newest successful deployed ledger row per image and PowerPoint uses the newest real PowerPoint capture. It goes stale loudly in CI.

colorwheel · graphic · 371×370

colorwheel source image — **Source** · original bitmap · 76 KB

Scripted runtime · LPIPS 0.0117 · SSIM 0.9752 · 1,389 splats · 226 KB · live JS/WebGL

Scriptless CSS · LPIPS 0.0122 · SSIM 0.9554 · 1,736 splats · 905 KB · live DOM

colorwheel as corrected-exporter SVG — **SVG** · LPIPS 0.0160 · SSIM 0.9469 · 1,736 splats · 961 KB · live vector

colorwheel deck rendered by real PowerPoint — **PowerPoint** · LPIPS 0.0222 · SSIM 0.9352 · 1,858 shapes · 146 KB · real capture · deck

logo · transparency · 384×384

Source · original bitmap · 115 KB

Scripted runtime · LPIPS 0.0971 · SSIM 0.9203 · 1,454 splats · 229 KB · live JS/WebGL

Scriptless CSS · LPIPS 0.0823 · SSIM 0.8969 · 1,517 splats · 791 KB · live DOM

SVG · LPIPS 0.0738 · SSIM 0.8969 · 1,517 splats · 1,482 KB · live vector

PowerPoint · LPIPS 0.1373 · SSIM 0.8846 · 1,572 shapes · 124 KB · real capture · deck

brick · texture · 384×384

brick source image — **Source** · original bitmap · 89 KB

Scripted runtime · LPIPS 0.0472 · SSIM 0.9722 · 1,449 splats · 269 KB · live JS/WebGL

Scriptless CSS · LPIPS 0.1388 · SSIM 0.8445 · 1,444 splats · 752 KB · live DOM

brick as corrected-exporter SVG — **SVG** · LPIPS 0.1080 · SSIM 0.8509 · 1,444 splats · 781 KB · live vector

brick deck rendered by real PowerPoint — **PowerPoint** · LPIPS 0.0863 · SSIM 0.8868 · 1,391 shapes · 100 KB · real capture · deck

text · text-like · 384×147

text source image — **Source** · original bitmap · 49 KB

Scripted runtime · LPIPS 0.1437 · SSIM 0.8903 · 954 splats · 167 KB · live JS/WebGL

Scriptless CSS · LPIPS 0.1337 · SSIM 0.8201 · 937 splats · 488 KB · live DOM

text as corrected-exporter SVG — **SVG** · LPIPS 0.1259 · SSIM 0.8319 · 937 splats · 878 KB · live vector

text deck rendered by real PowerPoint — **PowerPoint** · LPIPS 0.2536 · SSIM 0.2740 · 978 shapes · 88 KB · real capture · deck

chameleon · reference · 364×384

chameleon source image — **Source** · original bitmap · 166 KB

Scripted runtime · LPIPS 0.1284 · SSIM 0.9140 · 1,682 splats · 290 KB · live JS/WebGL

Scriptless CSS · LPIPS 0.1456 · SSIM 0.8748 · 1,634 splats · 852 KB · live DOM

chameleon as corrected-exporter SVG — **SVG** · LPIPS 0.1462 · SSIM 0.8678 · 1,634 splats · 1,566 KB · live vector

chameleon deck rendered by real PowerPoint — **PowerPoint** · LPIPS 0.1682 · SSIM 0.8723 · 1,778 shapes · 155 KB · real capture · deck

checkerboard · hard-edges · 200×200

checkerboard source image — **Source** · original bitmap · 1 KB

Scripted runtime · LPIPS 0.2349 · SSIM 0.5753 · 1,395 splats · 194 KB · live JS/WebGL

Scriptless CSS · LPIPS 0.1614 · SSIM 0.6120 · 1,411 splats · 734 KB · live DOM

checkerboard as corrected-exporter SVG — **SVG** · LPIPS 0.1499 · SSIM 0.6206 · 1,411 splats · 1,432 KB · live vector

checkerboard deck rendered by real PowerPoint — **PowerPoint** · LPIPS 0.4456 · SSIM 0.4682 · 1,755 shapes · 98 KB · real capture · deck

astronaut · portrait · 384×384

astronaut source image — **Source** · original bitmap · 235 KB

Scripted runtime · LPIPS 0.2534 · SSIM 0.7160 · 1,619 splats · 260 KB · live JS/WebGL

Scriptless CSS · LPIPS 0.2351 · SSIM 0.7016 · 1,623 splats · 846 KB · live DOM

astronaut as corrected-exporter SVG — **SVG** · LPIPS 0.1708 · SSIM 0.7796 · 1,623 splats · 1,598 KB · live vector

astronaut deck rendered by real PowerPoint — **PowerPoint** · LPIPS 0.3273 · SSIM 0.6132 · 1,822 shapes · 127 KB · real capture · deck

rocket · landscape · 384×256

rocket source image — **Source** · original bitmap · 120 KB

Scripted runtime · LPIPS 0.1878 · SSIM 0.8873 · 1,356 splats · 246 KB · live JS/WebGL

Scriptless CSS · LPIPS 0.1856 · SSIM 0.8335 · 1,379 splats · 718 KB · live DOM

rocket as corrected-exporter SVG — **SVG** · LPIPS 0.1888 · SSIM 0.7976 · 1,379 splats · 1,248 KB · live vector

rocket deck rendered by real PowerPoint — **PowerPoint** · LPIPS 0.2205 · SSIM 0.8385 · 1,489 shapes · 141 KB · real capture · deck

coffee · natural · 384×256

coffee source image — **Source** · original bitmap · 180 KB

Scripted runtime · LPIPS 0.2227 · SSIM 0.7751 · 1,429 splats · 241 KB · live JS/WebGL

Scriptless CSS · LPIPS 0.2386 · SSIM 0.7077 · 1,404 splats · 732 KB · live DOM

coffee as corrected-exporter SVG — **SVG** · LPIPS 0.2259 · SSIM 0.7061 · 1,404 splats · 1,344 KB · live vector

coffee deck rendered by real PowerPoint — **PowerPoint** · LPIPS 0.2575 · SSIM 0.6916 · 1,591 shapes · 136 KB · real capture · deck

moon · smooth-gradient · 384×384

moon source image — **Source** · original bitmap · 78 KB

Scripted runtime · LPIPS 0.2653 · SSIM 0.9338 · 1,276 splats · 237 KB · live JS/WebGL

Scriptless CSS · LPIPS 0.2114 · SSIM 0.9166 · 1,298 splats · 676 KB · live DOM

moon as corrected-exporter SVG — **SVG** · LPIPS 0.2333 · SSIM 0.8884 · 1,298 splats · 1,128 KB · live vector

moon deck rendered by real PowerPoint — **PowerPoint** · LPIPS 0.2157 · SSIM 0.9196 · 1,253 shapes · 122 KB · real capture · deck

chelsea · fur · 384×255

chelsea source image — **Source** · original bitmap · 161 KB

Scripted runtime · LPIPS 0.2443 · SSIM 0.8589 · 1,674 splats · 293 KB · live JS/WebGL

Scriptless CSS · LPIPS 0.2520 · SSIM 0.8052 · 1,664 splats · 867 KB · live DOM

chelsea as corrected-exporter SVG — **SVG** · LPIPS 0.2392 · SSIM 0.8060 · 1,664 splats · 1,567 KB · live vector

chelsea deck rendered by real PowerPoint — **PowerPoint** · LPIPS 0.2584 · SSIM 0.8152 · 1,787 shapes · 166 KB · real capture · deck

coins · grayscale · 384×303

coins source image — **Source** · original bitmap · 121 KB

Scripted runtime · LPIPS 0.2517 · SSIM 0.7409 · 1,157 splats · 196 KB · live JS/WebGL

Scriptless CSS · LPIPS 0.2429 · SSIM 0.7059 · 1,200 splats · 625 KB · live DOM

coins as corrected-exporter SVG — **SVG** · LPIPS 0.2406 · SSIM 0.7120 · 1,200 splats · 1,183 KB · live vector

coins deck rendered by real PowerPoint — **PowerPoint** · LPIPS 0.2715 · SSIM 0.7017 · 1,386 shapes · 97 KB · real capture · deck

cell · grayscale · 320×384

cell source image — **Source** · original bitmap · 44 KB

Scripted runtime · LPIPS 0.2361 · SSIM 0.9545 · 1,457 splats · 278 KB · live JS/WebGL

Scriptless CSS · LPIPS 0.2568 · SSIM 0.9389 · 1,419 splats · 740 KB · live DOM

cell as corrected-exporter SVG — **SVG** · LPIPS 0.2633 · SSIM 0.8975 · 1,419 splats · 1,225 KB · live vector

cell deck rendered by real PowerPoint — **PowerPoint** · LPIPS 0.2137 · SSIM 0.9433 · 1,389 shapes · 137 KB · real capture · deck

stereo_motorcycle · natural · 384×259

stereo_motorcycle source image — **Source** · original bitmap · 187 KB

Scripted runtime · LPIPS 0.3049 · SSIM 0.7202 · 1,419 splats · 229 KB · live JS/WebGL

Scriptless CSS · LPIPS 0.3149 · SSIM 0.6735 · 1,341 splats · 699 KB · live DOM

stereo_motorcycle as corrected-exporter SVG — **SVG** · LPIPS 0.2709 · SSIM 0.7185 · 1,341 splats · 1,308 KB · live vector

stereo_motorcycle deck rendered by real PowerPoint — **PowerPoint** · LPIPS 0.4003 · SSIM 0.6332 · 1,569 shapes · 118 KB · real capture · deck

camera · grayscale · 384×384

camera source image — **Source** · original bitmap · 121 KB

Scripted runtime · LPIPS 0.3673 · SSIM 0.7627 · 1,192 splats · 200 KB · live JS/WebGL

Scriptless CSS · LPIPS 0.3143 · SSIM 0.7517 · 1,248 splats · 650 KB · live DOM

camera as corrected-exporter SVG — **SVG** · LPIPS 0.3157 · SSIM 0.7509 · 1,248 splats · 1,217 KB · live vector

camera deck rendered by real PowerPoint — **PowerPoint** · LPIPS 0.3975 · SSIM 0.7312 · 1,279 shapes · 96 KB · real capture · deck

retina · smooth-gradient · 384×384

retina source image — **Source** · original bitmap · 165 KB

Scripted runtime · LPIPS 0.2357 · SSIM 0.8598 · 1,516 splats · 257 KB · live JS/WebGL

Scriptless CSS · LPIPS 0.3651 · SSIM 0.8051 · 1,547 splats · 806 KB · live DOM

retina as corrected-exporter SVG — **SVG** · LPIPS 0.3561 · SSIM 0.8008 · 1,547 splats · 1,506 KB · live vector

retina deck rendered by real PowerPoint — **PowerPoint** · LPIPS 0.4587 · SSIM 0.6655 · 1,523 shapes · 107 KB · real capture · deck

immunohistochemistry · texture · 384×384

immunohistochemistry source image — **Source** · original bitmap · 284 KB

Scripted runtime · LPIPS 0.4411 · SSIM 0.6467 · 1,651 splats · 276 KB · live JS/WebGL

Scriptless CSS · LPIPS 0.4226 · SSIM 0.6329 · 1,741 splats · 907 KB · live DOM

immunohistochemistry as corrected-exporter SVG — **SVG** · LPIPS 0.4164 · SSIM 0.6478 · 1,741 splats · 1,675 KB · live vector

immunohistochemistry deck rendered by real PowerPoint — **PowerPoint** · LPIPS 0.4661 · SSIM 0.6163 · 1,839 shapes · 151 KB · real capture · deck

hubble_deep_field · dark-sparse · 384×335

hubble_deep_field source image — **Source** · original bitmap · 226 KB

Scripted runtime · LPIPS 0.3935 · SSIM 0.5786 · 1,189 splats · 201 KB · live JS/WebGL

Scriptless CSS · LPIPS 0.4271 · SSIM 0.5696 · 953 splats · 496 KB · live DOM

hubble_deep_field as corrected-exporter SVG — **SVG** · LPIPS 0.4212 · SSIM 0.5642 · 953 splats · 930 KB · live vector

hubble_deep_field deck rendered by real PowerPoint — **PowerPoint** · LPIPS 0.4580 · SSIM 0.5871 · 1,074 shapes · 80 KB · real capture · deck

page · text-like · 384×191

page source image — **Source** · original bitmap · 76 KB

Scripted runtime · LPIPS 0.4918 · SSIM 0.7039 · 1,009 splats · 163 KB · live JS/WebGL

Scriptless CSS · LPIPS 0.4586 · SSIM 0.6530 · 960 splats · 500 KB · live DOM

page as corrected-exporter SVG — **SVG** · LPIPS 0.4552 · SSIM 0.6639 · 960 splats · 943 KB · live vector

page deck rendered by real PowerPoint — **PowerPoint** · LPIPS 0.5501 · SSIM 0.4068 · 1,049 shapes · 76 KB · real capture · deck

gravel · texture · 384×384

gravel source image — **Source** · original bitmap · 184 KB

Scripted runtime · LPIPS 0.5311 · SSIM 0.5176 · 1,260 splats · 201 KB · live JS/WebGL

Scriptless CSS · LPIPS 0.5470 · SSIM 0.4131 · 1,263 splats · 658 KB · live DOM

gravel as corrected-exporter SVG — **SVG** · LPIPS 0.5026 · SSIM 0.5146 · 1,263 splats · 727 KB · live vector

gravel deck rendered by real PowerPoint — **PowerPoint** · LPIPS 0.5372 · SSIM 0.4735 · 1,387 shapes · 94 KB · real capture · deck

grass · texture · 384×384

grass source image — **Source** · original bitmap · 210 KB

Scripted runtime · LPIPS 0.5287 · SSIM 0.4624 · 1,346 splats · 220 KB · live JS/WebGL

Scriptless CSS · LPIPS 0.5222 · SSIM 0.4258 · 1,295 splats · 675 KB · live DOM

grass as corrected-exporter SVG — **SVG** · LPIPS 0.5203 · SSIM 0.4252 · 1,295 splats · 744 KB · live vector

grass deck rendered by real PowerPoint — **PowerPoint** · LPIPS 0.5479 · SSIM 0.3926 · 1,361 shapes · 95 KB · real capture · deck
